Lovibond/Tintometer Color Measurement | ||||||||
Products:
|
 |
||||||||
| In the 1860s, Joseph
Lovibond, the founder of The Tintometer Ltd, developed the original Lovibond
Color system, which was based on a calibrated series of red, yellow and
blue glas color standards. Today companies throughout the world use
Lovibond colorimeters in the analysis of products such as edible and industrial
oils, fuel oils, chemicals, coatings and beverages. Over the years
the Lovibond brand has become the hallmark for color measurement in processing
industries, recognised by major international standardising bodies, who
quote our equipment in their specifications for color management (in particular
ASTM standards and AOCS methods). Tintometer’s unparalleled knowledge
is embodied into the Lovibond range of instruments, from the visual comparators
for grading single color scales through to flexible, full-scale spectrophotometric
instruments for objective colorimetry and data analysis.
The range of Lovibond colorimeters covers the key color scales and color values that are used by industry for color control: | |||||||||
| ADMI Color | APHA Color | AOCS-Tintometer Color | ASBC Color (American Society for Brewing Chemists) | ASTM Color |
| Barrett Scale | beta Carotene | Brown Scale | ChinesePharmacopoeia (CP) Color | Chlorophyll A & B |
| Dichromate Color Index | Dyed Aviation Gasoline | EBC Color (European Brewery Convention) | European Pharmacopoeia(EP) Color | FAC Color |
| Gardner Color | Hazen Units | Hess-Ives Color Units | HoneyColor | ICUMSA Color Index |
| International Fruit Juice Union (IFU) Color | IodineColor | IP Units | Klett Color (blue filter KS-42) | Kreis Value |
| Lovibond RYBNColor | Maple Syrup | Paint Research Station (PRS) Color | Pfund Equivalents | PlatinumCobalt Color Scale |
| Rosin - French (Bordeaux) Color | Rosin - Indian | Rosin- US Naval Stores | Saybolt Color | Series 52 Color |
| Tanning Extracts | US NavalStores Rosin | US Pharmacopoeia (USP) Color | Whiteness Index | Yellowness Index |
| XYZtristimulus values | xyY chromaticity co-ordinates | CIE Lab color space | CIELCh color space | CIE uvY color space |
| Hunter Lab color space | DEcolor difference | Transmittance | Absorptance | Optical density |
Lovibond color measuring instruments meet the requirements specified
in the internationally recognised standard test methods for colorimetry, in particular:
| AOCS Method | Scope | Color Scale/Test |
| AOCS Cc 13a | Animal fats and all fats and oils too dark to be graded by the Wesson method | FAC Color |
|
AOCS Cc 13b
(Wesson Method) |
Normal oils and fats | AOCS-Tintometer Color |
|
AOCS Cc 13e
|
Normal animal and vegetable oils and fats | Lovibond RYBN Color |
|
AOCS Cc 13j
|
Color refined oils and tallows | AOCS-Tintometer Color, Lovibond RYBN Color |
|
AOCS Td 1a
|
Natural and synthetic drying oils, fatty acids and oil derivatives | Gardner Color |
|
AOCS Td 1b
|
Light colored
industrial oils and derivatives such as certain fatty nitrogen compounds
|
Platinum
Cobalt Color, Hazen Units, APHA Color
|
|
AOCS Td 3a
|
Color stability of fatty acids after heating | Gardner Color |
|
ASTM Standard
|
Scope | Color Scale/Test |
|
ASTM D156
|
Light colored petroleum products | Saybolt Color |
|
ASTM D509
|
Rosins | Rosin, US Naval Stores |
|
ASTM D565
|
Quality testing of white mineral oils | |
|
ASTM D848
|
Quality testing of industrial aromatic hydrocarbons | Acid Wash Color |
|
ASTM D1209
|
Clear liquids | Pt-Co/Hazen/APHA Units |
|
ASTM D1363
|
Impurities in acetone and methanol | |
|
ASTM D1500
|
Petroleum products | ASTM Color |
|
ASTM D1544
|
Transparent liquids | Gardner Color |
|
ASTM D2392
|
Aviation gasolines | Dyed aviation gasoline |
|
ASTM D6166
|
Naval stores and related products | Gardner Color |
|
ASTM D6045
|
Petroleum products (by the automatic tristimulus method) | ASTM Color, Saybolt Color |
